6 Zone Air Compression Back Stretcher Neck to Thigh

2026-10-19



The six-zone air compression mattress for the back. Lying supine, the user selects which chambers to activate — neck, upper back, mid back, lumbar, hip and thigh — then chooses one of five inflation patterns and a pressure between 30 and 250 mmHg. The control unit inflates and deflates the chambers in sequence, so the compression travels along the back instead of sitting in one place. A 10–60 minute timer ends the session automatically, and Pause releases all air immediately. The mattress rolls up after use, and the touch panel keeps every setting within reach. Supplied with control unit, air tube and power adapter.

Product Highlights

  • 6 independent air zones — neck, upper back, mid back, lumbar, hip and thigh; switch any chamber on or off from the panel.
  • 30–250 mmHg adjustable pressure with 5 inflation patterns (A–E) and a 10–60 minute timer.
  • Pause deflates instantly — press Pause and every chamber releases; restart when ready.
  • Quiet and compact — ≤55 dB operating noise, 26 W maximum power; suits clinics as well as home use.
  • Roll-up mattress, wipe-clean surface — two-way stretch PU, cleaned with 75% alcohol; stores flat between sessions.


Detail Page Copy

01 — Hero

6-Zone Air Compression Back Stretcher

Intermittent air compression along the whole back — neck to thigh. 6 air zones · 5 modes A–E · 30–250 mmHg · 10–60 min · ≤55 dB · 26 W

02 — Six zones

Six zones, neck to thigh

Pick the zones you want with keys 1 to 6. Each one works on its own. Steady light = active · blinking = inflating · run all six zones or isolate one region.

03 — Five modes

Five patterns, A to E

Choose the sequence on the panel. Cycle times are approximate.

Mode What it does Cycle
A — Wave one zone inflates at a time, through all six ~12 s per zone
B — Build-up one more zone every 12 s until all six are inflated ~72 s
C — Paired zones 1+2, then 3+4, then 5+6 ~75 s
D — Full all six zones together ~97 s
E — Combined Mode A then Mode B ~165 s

04 — Set up

Ready in four steps

No tools needed. Lay the mattress on a flat, firm surface.

  1. Unroll flat — yoga mat or floor, head at Zone 1.
  2. Fit the air tube — align the triangle marks, push in fully.
  3. Connect power — touch keys respond immediately.
  4. Lie down and start — set zones, mode, time, pressure. First use: start low, then raise the pressure gradually. Pause at any time — the chambers deflate while paused.

05 — Storage

Rolls up, stores flat

Air releases in seconds, so the mattress packs down between sessions. Carry in one hand · Room to room · Wipe with 75% alcohol, never rinse · Ventilated storage, away from heat.


Specifications

Item Specification
Model FO3003C
Air channels 6 zones
Modes A, B, C, D, E
Pressure range 30–250 mmHg, adjustable
Inflation time about 12–18 s per channel
Timer 10–60 min (±5 min)
Operating noise ≤55 dB
Rated input DC 12 V / 2000 mA
Power supply 220 V ±22 V, 50 Hz ±1 Hz
Maximum working current 2100 mA
Maximum power 26 W
Ambient temperature 5–40 °C
Relative humidity ≤80%
Atmospheric pressure 86–106 kPa
Mattress Two-way stretch PU, 6 air chambers
Working principle Air-flow switching inflates the chambers in sequence, applying intermittent air pressure for a compression massage effect
